Jumper SF800MINI Futaba S-FHSS

Jumper SF800MINI Receiver Futaba S-FHSS Protocal 8CH s.bus Receiver for FUTABA S-FHSS T4YF T6J T6K T10J T14SG T18MZ Transmitter

Specification:

Item name: SF800MINI FUTABA S-FHSS compatible receiver

Weight: 2.8g

Size(L*W*H): 22mm*15mm*3mm

Working current: 48mA max

Working voltage: 3.5 ~6.0V

Sensitivity: about -95dBm

Ouput mode: S.BUS/ CPPM

Compatible with FUTABA S-FHSS, T4YF, T6J, T6K, T10J, T14SG, T18MZ ,T18SZ transmitter

Bind:

Press and hold the binding button, and supply power to the receiver, the green LED keep light means binding succeed.

Signal switching:

-Long press the binding button 6-10s, lossen, the green LED flashing

-When the green LED quick blink, press the binding button again, the red LED light means CPPM switch to SBUS

-When the green LED slowly blink, press the binding button again, the red LED light means SBUS swtich to CPPM

Package included:

1* SF800MINI FUTABA S-FHSS compatible receiver
