iFlight iPower GM110-8 Gimbal Motor + AS5048A Encoder

The principle of the camera stabilization using brushless direct drive motors, In fact, gimbal based on BLDC motors is very similar to regular gimbal based on hobby servo.

Features:

-Sealed Case to prevent contamination by dust and dirt.

-Hollow shaft for slipring

-Configuration:24N28P,provide more torque.

Specs:

Model No.:GM110-8 w/encoder

Weight:559

Dimension(mm):110*34

RPM:334-370

Torque (g):9000-15000

Voltage (V):20V

Cunnrent (A):0.56

Configuration:24N28P

Winding Turns:0.33*1-150T

Resistance(Ω):5.57Ω

Hollow Shaft Diameter (mm):12.6
