DJI FPV Drone + Remote control + Goggles Combo

FPV → DJI FPV Drone → DJI FPV Drone + Remote control + Goggles Combo
₽136056
$1788
в магазине
 65Drones

В наличии
Рекомендуемые магазины
 ReadyMadeRC
Доставка
LiteMF
Нет на складе
₽76018
$999
↓ Цены в других магазинах
DJI FPV Drone + Remote control + Goggles Combo

Specifications:

Aircraft Takeoff Weight Approx. 795 g
Dimensions 255×312×127 mm (with propellers)
178×232×127 mm (without propellers)
Diagonal Distance 245 mm
Max Ascent Speed

M mode: No limit

S mode: 15 m/s

N mode: 8 m/s

Max Descent Speed

M mode: No limit

S mode: 10 m/s

N mode: 5 m/s

Max Speed 140 km/h(100km/h in Mainland China)
M mode: 39 m/s (27 m/s in Mainland China)
S mode: 27 m/s
N mode: 15 m/s
Max Acceleration 0-100 kph: 2 s (in ideal conditions while flying in M mode)
Max Service Ceiling Above Sea Level 6,000 m
Max Flight Time(without wind) Approx. 20 mins (measured while flying at 40 kph in windless conditions)
Max Hover Time Approx. 16 mins (measured when flying in windless conditions)
Max Flight Distance 16.8 km (measured while flying in windless conditions)
Max Wind Speed Resistance 39-49 kph (25-31 mph)
Number of Antennas Four
GNSS GPS+GLONASS+GALILEO
Hovering Accuracy Range Vertical:
±0.1 m (with Vision Positioning) ±0.5 m (with GPS positioning)
Horizontal:
±0.3 m (with Vision Positioning) ±1.5 m (with GPS positioning)
Supported SD Cards microSD (up to 256 GB)
Operating Temperature -10° to 40° C (14° to 104° F)
Internal Storage N/A
Camera Sensor 1/2.3” CMOS
Effect pixels: 12 million
Lens FOV: 150°
35mm Format Equivalent: 14.66 mm
Aperture: f/2.8
Focus Mode: Fixed Focus
Focus Range: 0.6 m to ∞
ISO 100-12800
Shutter Speed 1/50-1/8000 s
Still Photography Modes Single shot
Max Image Size 3840×2160
Photo Format JPEG
Video Resolution 4K: 3840×2160 at 50/60fps
FHD: 1920×1080 at 50/60/100/120fps

Video Formats MP4/MOV (H.264/MPEG-4 AVC, H.265/HEVC)
Max Video Bitrate 120 Mbps
Color Profile Standard, D-Cinelike
RockSteady EIS Available
Distortion Correction Available
Supported File Formats exFAT (recommended)
FAT32
Gimbal Mechanical Range Tilt: -65° to 70°
Controllable Range Tilt: -50° to 58°
Stabilization Single-axis (tilt), electronic roll axis
Max Control Speed 60°/s
Angular Vibration Range ±0.01° (N mode)
Electronic Roll Axis Available (can stabilize footage when the aircraft is tilted at angles of up to 10°)
Sensing System Forward Precision Measurement Range: 0.5-18 m
Obstacle Sensing: Available in N mode only
FOV: 56° (horizontal), 71° (vertical)
Downward (dual vision sensors + TOF) TOF Effective Sensing Height: 10 m
Hovering Range: 0.5-15 m
Vision Sensor Hovering Range: 0.5-30 m
Downward Auxillary Light Single LED
Operating Environment

Refers to non-reflective, discernible surfaces

Diffuse reflectivity >20% (e.g. walls, trees, people)
Adequate lighting conditions (lux >15 in normal indoor lighting conditions)

Video Transmission Operating Frequency 2.400-2.4835 GHz
5.725-5.850 GHz
Communication Bandwidth 40 MHz (Max.)
Live View Mode Low-Latency Mode: 810p/120fps ≤ 28ms
High-Quality Mode: 810p/60fps ≤ 40ms
Max Video Bitrate 50 Mbps
Transmission Range 10 km (FCC), 6 km (CE), 6 km (SRRC), 6 km (MIC)
Audio Transmission Support Yes
DJI FPV Goggles V2 Weight Approx. 420 g (headband and antennas included)
Dimensions 184×122×110 mm (antennas excluded)
202×126×110 mm (antennas included)
Screen Size 2-inches (×2)
Screen Refresh Rate 144 Hz
Communication Frequency <sup>[1]</sup> 2.400-2.4835 GHz
5.725-5.850 GHz
Transmitter Power (EIRP)

2.400-2.4835 GHz
FCC: ≤ 28.5 dBm

CE: ≤ 20 dBm

SRRC: ≤ 20 dBm

MIC: ≤ 20 dBm


5.725-5.850 GHz
FCC: ≤ 31.5 dBm

CE: ≤ 14 dBm

SRRC: ≤ 19 dBm

Communication Bandwidth 40 MHz (Max.)
Live View Mode Low-Latency Mode: 810p/120fps ≤ 28ms*
High-Quality Mode: 810p/60fps ≤ 40ms*
* A 150° FOV is available when shooting at 50 or 100 fps. For other frame rates, the FOV will be 142°.
Max Video Bitrate 50 Mbps
Transmission Range 10 km (FCC), 6 km (CE), 6 km (SRRC), 6 km (MIC)
Video Format MP4 (Video format: H.264)
Supported Video and Audio Playback Formats MP4, MOV, MKV (Video format: H.264; Audio format: AAC-LC, AAC-HE, AC-3, MP3)
Operating Temperature 0° to 40° C (32° to 104° F)
Power Input Dedicated DJI Goggles batteries or other 11.1.-25.2 V batteries.
FOV FOV: 30° to 54°; Image size: 50-100%
Interpupillary Distance Range 58-70 mm
Supported microSD Cards microSD (up to 256 GB)
DJI FPV Remote Controller Operating Frequency 2.400-2.4835 GHz
5.725-5.850 GHz
Transmitter Power (EIRP) 2.400-2.4835 GHz
FCC: ≤ 28.5 dBm CE: ≤ 20 dBm SRRC: ≤ 20 dBm MIC: ≤ 20 dBm
5.725-5.850 GHz
FCC: ≤ 31.5 dBm CE: ≤ 14 dBm SRRC: ≤ 19 dBm
Max. Transmission Distance 10 km (FCC), 6 km (CE), 6 km (SRRC), 6 km (MIC)
Gimbal Dimensions 190×140×51 mm
Weight 346 g
Battery Life Approx. 9 hours
Charging Time 2.5 hours
Motion Controller Model FC7BMC
Weight 167 g
Operating Frequency Range 2.400-2.4835 GHz; 5.725-5.850 GHz
Max Transmission Distance (unobstructed, free of interference) 10 km (FCC), 6 km (CE/SRRC/MIC)
Transmitter Power (EIRP) 2.4 GHz: ≤28.5 dBm (FCC), ≤20 dBm (CE/ SRRC/MIC)
5.8 GHz: ≤31.5 dBm (FCC), ≤19 dBm (SRRC), ≤14 dBm (CE)
Operating Temperature Range -10° to 40° C (14° to 104° F)
Battery Life 300 minutes
microSD Card Supported microSD cards Max 256 GB
UHS-I Speed Grade 3
Recommended microSD cards SanDisk High Endurance U3 V30 64GB microSDXC
SanDisk Extreme PRO U3 V30 A2 64GB microSDXC
SanDisk Extreme U3 V30 A2 64GB microSDXC
SanDisk Extreme U3 V30 A2 128GB microSDXC
SanDisk Extreme U3 V30 A2 256GB microSDXC
Lexar 667x V30 128GB microSDXC
Lexar High Endurance 128GB U3 V30 microSDXC
Samsung EVO U3 (Yellow) 64GB microSDXC
Samsung EVO Plus U3 (Red) 64GB microSDXC
Samsung EVO Plus U3 256GB microSDXC
Netac 256GB U3 A1 microSDXC
Goggles Battery Capacity 1800 mAh
Voltage 9 V (Max.)
Type LiPo 2S
Energy 18 Wh
Charging Temperature 0° to 45° C
Max Charging Power 10 W
Battery Life Approx. 110 minutes (measured in an environment of 25°C at maximum brightness level)
Intelligent Flight Battery Battery Capacity 2000 mAh
Voltage 22.2 V
Max Charging Voltage 25.2 V
Battery Type LiPo 6S
Energy 44.4 Wh@0.5C
Discharge Rate Standard: 10C
Weight 295 g
Charging Temperature 5° to 40° C (41° to 104° F)
Max Charging Power 90 W
Charger Output

Battery charging interface:
25.2 V ± 0.1 V
3.57 A ± 0.1 A (high current)

1 A ± 0.2 A (low current)
USB Port: 5V/2A (×2)

Rated Power 90 W


Note:

1. Due to local policy and regulation restrictions, the 5.8 GHz frequency band is currently banned in certain countries, including but not limited to Japan, Russia, Israel, Ukraine, and Kazakhstan. Please use the 2.4 GHz frequency band when operating in these locations. Always check local rules and regulations before use, as they may change over time.

2. Maximum flight range specification is a proxy for radio link strength and resilience, not aircraft battery capability. It only refers to the maximum, one-way flight distance. Data was measured in an open environment without interference. Please pay attention to the return prompt on the DJI Fly app during actual flight. Refer to the following applicable standard in different countries and regions:

FCC: United States, Australia, Canada, Hong Kong, Taiwan, Chile, Colombia, Puerto Rico, and other regions;

SRRC: Mainland China;

CE: UK, Russia, France, Germany, Portugal, Spain, Switzerland, Macau, New Zealand, UAE, and other regions;

MIC: Japan.


Package Included:

1 x DJI FPV Racing Drone

1 x DII Remote Controller

1 x DJI FPV Goggles V2

8 x Propeller (4XCW 4XCCW)

Поделиться

Цены на DJI FPV Drone + Remote control + Goggles Combo в магазинах

Найдено предложений: 24 (NewBeeDrone2, ReadyMadeRC1, Banggood1, 65Drones1)

МагазинОстаток на складеЦена лотаЦена доставкиКупон / промокодКоличество в лотеЦена за единицу
ReadyMadeRCНет на складе₽76018
$999
1₽76018
$999
BanggoodНет на складе₽96107
$1219
1₽96107
$1219
NewBeeDroneНа складе: 10₽98846
$1299
1₽98846
$1299
NewBeeDroneНа складе: 8₽98846
$1299
1₽98846
$1299
65DronesВ наличии₽136056
$1788
1₽136056
$1788
